CECIL E. HANSON COLLECTION
ANTIQUE SURVEYING INSTRUMENTS

FOREIGN TRANSITS AND THEODOLITES

Tobin* - France

Serial Number:
Type: Transit
Telescope Length:
Diameter of Horizontal Circle:
Needle Length:
Diameter of Vertical Arc:
Height:
Weight:
Box: No
Condition: Good
Found:
CEH Inventory# FT7

*CEH listed the maker as "Tobin" in his inventory, but can find no markings on the instrument that would indicate this. There is "378" stamped on the base that might be the serial number. Have not found a reference to Tobin as an instrument maker in France. Looks similar to Morin transits - see below.

https://en.expertissim.com/brass-theodolite-signed-h-morin-12120985

Brass theodolite signed H.Morin.

Brass theodolite, signed "H.Morin, 11 rue Dulong à Paris".

Adjustable telescope for vertical and horizontal. Optical axis with pinion gears and knob. Elevation tangent scale and azimuth scale with silver limbe. Spirit/bubble level on the plate. Secondary, adjustment telescope with magnetic needle, under the plate. Tripod base with three leveling screws.

With its case.

Circa 1900.

Dimensions: Height: 27 cm (10-1/2 in.).
Length: of telescope: 21 cm (8-1/4 in.).
Dimensions of case: Height: 35 cm (13-3/4 in.). Width: 20 cm (7-3/4 in.). Depth: 25 cm (9-3/4 in.).
